压垫焊接式管接头
 |
|
| 管子外径DO |
公称通径DN |
d |
| 6 |
3 |
M10×1 |
| 10 |
6 |
M10×1 |
| 10 |
6 |
M14×1.5 |
| 14 |
8 |
M14×1.5 |
| 14 |
8 |
M18×1.5 |
| 18 |
10 |
M18×1.5 |
| 18 |
10 |
M22×1.5 |
| 22 |
15 |
M22×1.5 |
| 22 |
15 |
M27×2 |
| 28 |
20 |
M27×2 |
| 28 |
20 |
M33×2 |
| 34 |
25 |
M33×2 |
| 34 |
25 |
M42×2 |
| 42 |
32 |
M42×2 |
| 42 |
32 |
M48×2 |
| 50 |
40 |
M48×2 |
|
|
JB966-77
JB1883-77
|
|
|
焊接式端直通管接头
JB966-77 |
|
|
|
焊接式端直通长管接头
JB1883-77 |
|
|
| 管子外径DO |
公称通径DN |
| 6 |
3 |
| 10 |
6 |
| 14 |
8 |
| 18 |
10 |
| 22 |
15 |
| 28 |
20 |
| 34 |
25 |
| 42 |
32 |
| 50 |
40 |
|
|
JB970-77
JB971-77 |
|
|
焊接式直通管接头
JB970-77 |
|
|
|
焊接式直角管接头
JB971-77 |
|
|
|
|
焊接式三通管接头
JB972-77 |
焊接式隔壁直角管接头
JB975-77
|
|
|
|
|
焊接式四通管接头
JB973-77 |
焊接式分管管接头
JB977-77
|
|
| 管子外径DO |
公称通径DN |
| 6 |
3 |
| 10 |
6 |
| 14 |
8 |
| 18 |
10 |
| 22 |
15 |
| 28 |
20 |
| 34 |
25 |
| 42 |
32 |
| 50 |
40 |
|
焊接式隔壁直通管接头
JB974-77 |
 |
| 管子外径DO |
公称通径DN |
d |
| 10 |
6 |
M10×1 |
| 14 |
8 |
M14×1.5 |
| 18 |
10 |
M18×1.5 |
| 22 |
15 |
M22×1.5 |
| 28 |
20 |
M27×2 |
| 34 |
25 |
M33×2 |
| 42 |
32 |
M42×2 |
| 50 |
40 |
M48×2 |
|
|
焊接式铰接管接头JB978-77
|
 |
|
管子外径DO
|
公称通径DN
|
d
|
|
10
|
6
|
Z1/8
|
|
14
|
8
|
Z1/4
|
|
18
|
10
|
Z3/8
|
|
22
|
15
|
Z1/2
|
|
28
|
20
|
Z3/4
|
|
34
|
25
|
Z1
|
|
42
|
32
|
Z11/4
|
|
50
|
40
|
Z11/2
|
|
|
焊接式端直通锥螺蚊管接头JB/ZQ4399-86
|
JB/ZQ4399-86
JB/ZQ4400-86
|
 |
|
焊接式端直通锥螺蚊T长管接头JB/ZQ4400-86
|
|
|
|
